NETGEAR M4100 Series - View Switch Statistics

Configure System Information
28
M4100 Series Managed Switch
View Switch Statistics
 To view the switch statistics:
1. Prepare your computer with a static IP address in the 169.254.100.0 subnet, for
example, 169.254.100.201.
2. Connect an Ethernet cable from an Ethernet port on your computer to an Ethernet port on
the switch.
3. Launch a web browser
.
4. Enter the IP address of the switch in the web browser address field.
The default IP address of the switch is 169.254.100.100.
The Login screen displays.
5. Enter the user name and password.
The default admin user name is admin and the default admin password is blank, that is,
do not enter a password.
6. Click the Login button.
The web management interface menu displays.
7. Select System > Management > Switch Statistics.
8. Click the CLEAR button to clear all the counters, resetting all switch summary and detailed
statistics to default values. The discarded packets count cannot be cleared.
