Monitoring the System
371
M4100 Series Managed Switch
• To refresh the screen and display the current statistics, click the REFRESH button.
The following table describes the port statistics fields.
Table 99. Port statistics
Field Description
Interface The interface of the interface table entry associated with this port on an
adapter
.
Total Packets Received
Without Errors
The total number of packets received that were without errors.
Packets Received With Error The number of inbound packets that contained errors preventing them from
being deliverable to a higher-layer protocol.
Broadcast Packets Received The total number of good packets received that were directed to the
broadcast address. Note that this does not include multicast packets.
Packets Transmitted Without
Errors
The number of frames that were transmitted by this port to its segment.
Transmit Packet Errors The number of outbound packets that could not be transmitted because of
errors.
Collision Frames The best estimate of the total number of collisions on this Ethernet segment.
Time Since Counters Last
Cleared
The elapsed time in days, hours, minutes, and seconds since the statistics
for this port were last cleared.
View Detailed Port Statistics
To view detailed port statistics:
1. Prepare your computer with a static IP address in the 169.254.100.0 subnet, for
example, 169.254.100.201.
2. Connect an Ethernet cable from an Ethernet port on your computer to an Ethernet port on
the switch.
3. Launch a web browser
.
4. Enter the IP address of the switch in the web browser address field.
The default IP address of the switch is 169.254.100.100.
The Login screen displays.
5. Enter the user name and password.
The default admin user name is admin and the default admin password is blank, that is,
do not enter a password.
6. Click the Login button.
The web management interface menu displays.
