NETGEAR M4100 Series User Manual

Configure Switching Information
185
M4100 Series Managed Switch
13. Click the APPLY button.
The updated configuration is sent to the switch. Configuration changes take effect
immediately
.
The following table describes the nonconfigurable information displayed on the screen.
Table 57. MVR Configuration
Field Definition
MVR Max Multicast Groups Displays the maximum number of multicast groups
that MVR supports.
MVR Current Multicast Groups Displays current number of the MVR groups
allocated.
Configure MVR Groups
 To configure MVR groups:
1. Prepare your computer with a static IP address in the 169.254.100.0 subnet, for
example, 169.254.100.201.
2. Connect an Ethernet cable from an Ethernet port on your computer to an Ethernet port on
the switch.
3. Launch a web browser
.
4. Enter the IP address of the switch in the web browser address field.
The default IP address of the switch is 169.254.100.100.
The Login screen displays.
5. Enter the user name and password.
The default admin user name is admin and the default admin password is blank, that is,
do not enter a password.
6. Click the Login button.
The web management interface menu displays.
7. Select Switching > MVR > Advanced > MVR Group Configuration.
8. In the MVR Group IP list, specify the IP address for the new MVR group.
9. In the Count field, specify the number of contiguous MVR groups.

NETGEAR M4100 Series Specifications

General

Model	M4100 Series
Switch Type	Managed
Form Factor	Rack-mountable
Port Configuration	24 or 48 ports
Ethernet Ports	10/100/1000 Mbps
PoE Support	Available on some models (PoE and PoE+)
Layer	Layer 2/Layer 3
Management	Web-based, CLI, SNMP
VLAN Support	Yes
QoS	Yes
Stackable	Yes
Ports	24 or 48
Jumbo Frame Support	Yes
Security Features	ACL, 802.1X, RADIUS, TACACS+
Operating Temperature	0° to 50° C (32° to 122° F)
Storage Temperature	-20° to 70° C (-4° to 158° F)
Power Supply	Internal power supply
