Configure Switching Information
192
M4100 Series Managed Switch
The following table describes the nonconfigurable information displayed on the screen.
Table 60. MAC Address Table
Field Description
Total MAC Address Displaying the number of total MAC addresses learned or configured.
MAC Address A unicast MAC address for which the switch has forwarding or filtering
information.
The format is a 6 byte MAC address that is separated by
colons, for example, 01:23:45:67:89:AB.
VLAN ID The VLAN ID associated with the MAC address.
Port The port on which this address was learned.
Status The status of this entry. The meanings of the values are as follows:
• Static. the value of the corresponding instance was added by the
system or a user and cannot be relearned.
• Learned. the value of the corresponding instance was learned,
and is being used.
• Management. the value of the corresponding instance is also the
value of an existing instance of dot1dStaticAddress.
Configure Dynamic Addresses Aging Interval
You can set the address aging interval for the specified forwarding database.
To set the address aging interval:
1. Prepare your computer with a static IP address in the 169.254.100.0 subnet, for
example, 169.254.100.201.
2. Connect an Ethernet cable from an Ethernet port on your computer to an Ethernet port on
the switch.
3. Launch a web browser
.
4. Enter the IP address of the switch in the web browser address field.
The default IP address of the switch is 169.254.100.100.
The Login screen displays.
5. Enter the user name and password.
The default admin user name is admin and the default admin password is blank, that is,
do not enter a password.
6. Click the Login button.
The web management interface menu displays.
