Monitoring the System
379
M4100 Series Managed Switch
The following table describes EAP statistics.
Table 101. EAP statistics
Field Description
Port Selects the port to be displayed. When the selection is changed, a screen
refresh occurs causing all fields to be updated for the newly selected port.
All physical interfaces are valid.
PAE Capabilities This displays the PAE capabilities of the selected port.
EAPOL Frames Received This displays the number of valid EAPOL frames of any type that were
received by this authenticator
.
EAPOL Frames Transmitted This displays the number of EAPOL frames of any type that were
transmitted by this authenticator
.
EAPOL Start Frames
Received
This displays the number of EAPOL start frames that were received by this
authenticator
.
EAPOL Logoff Frames
Received
This displays the number of EAPOL logoff frames that were received by this
authenticator
.
EAPOL Last Frame Version This displays the protocol version number carried in the most recently
received EAPOL frame.
EAPOL Last Frame Source This displays the source MAC address carried in the most recently received
EAPOL frame.
EAPOL Invalid Frames
T
ransmitted
This displays the number of EAPOL frames that were received by this
authenticator in which the frame type is not recognized.
EAPOL Length Error Frames
Received
This displays the number of EAPOL frames that were received by this
authenticator in which the frame type is not recognized.
EAP Response/ID Frames
Received
This displays the number of EAP response/identity frames that were
received by this authenticator
.
EAP Response Frames
Received
This displays the number of valid EAP response frames (other than resp/ID
frames) that were received by this authenticator
.
EAP Request/ID Frames
T
ransmitted
This displays the number of EAP request/identity frames that were
transmitted by this authenticator.
EAP Request Frames
T
ransmitted
This displays the number of EAP request frames (other than request/identity
frames) that were transmitted by this authenticator.
Perform a Cable Test
 To perform a cable test:
1. Prepare your computer with a static IP address in the 169.254.100.0 subnet, for
example, 169.254.100.201.
2. Connect an Ethernet cable from an Ethernet port on your computer to an Ethernet port on
the switch.
3. Launch a web browser
.

NETGEAR M4100 Series Specifications

General

Model	M4100 Series
Switch Type	Managed
Form Factor	Rack-mountable
Port Configuration	24 or 48 ports
Ethernet Ports	10/100/1000 Mbps
PoE Support	Available on some models (PoE and PoE+)
Layer	Layer 2/Layer 3
Management	Web-based, CLI, SNMP
VLAN Support	Yes
QoS	Yes
Stackable	Yes
Ports	24 or 48
Jumbo Frame Support	Yes
Security Features	ACL, 802.1X, RADIUS, TACACS+
Operating Temperature	0° to 50° C (32° to 122° F)
Storage Temperature	-20° to 70° C (-4° to 158° F)
Power Supply	Internal power supply
