NETGEAR M4100 Series User Manual

Monitoring the System
380
M4100 Series Managed Switch
4. Enter the IP address of the switch in the web browser address field.
The default IP address of the switch is 169.254.100.100.
The Login screen displays.
5. Enter the user name and password.
The default admin user name is admin and the default admin password is blank, that is,
do not enter a password.
6. Click the Login button.
The web management interface menu displays.
7. Select Monitoring
 Ports > Cable Test.
8. Select the check box for the port to which the cable to be tested is connected.
9. Click the APPL
Y button.
A cable test is performed on the selected port.
The cable test might take up to two seconds
to complete. If the port has an active link, the cable status is always Normal. The
command returns a cable length estimate if this feature is supported by the PHY for the
current link speed. If the link is down and a cable is attached to a 10/100 Ethernet
adapter, then the cable status can be Open or Short because some Ethernet adapters
leave unused wire pairs unterminated or grounded.

NETGEAR M4100 Series Specifications

General

Model	M4100 Series
Switch Type	Managed
Form Factor	Rack-mountable
Port Configuration	24 or 48 ports
Ethernet Ports	10/100/1000 Mbps
PoE Support	Available on some models (PoE and PoE+)
Layer	Layer 2/Layer 3
Management	Web-based, CLI, SNMP
VLAN Support	Yes
QoS	Yes
Stackable	Yes
Ports	24 or 48
Jumbo Frame Support	Yes
Security Features	ACL, 802.1X, RADIUS, TACACS+
Operating Temperature	0° to 50° C (32° to 122° F)
Storage Temperature	-20° to 70° C (-4° to 158° F)
Power Supply	Internal power supply
