NETGEAR M4100 Series User Manual

Monitoring the System
372
M4100 Series Managed Switch
7. Select Monitoring  Ports> Port Detailed Statistics.
You can use the buttons at the bottom of the screen to perform the following actions:
• T
o clear all counters, click the CLEAR button.
This resets all statistics for this port to the default values.
• T
o refresh the data on the screen and display the most current statistics, click the
REFRESH button.
The following table describes the detailed port information displayed on the screen. To view
information about a different port, select the port number from the Interface menu.
Table 100. Port Detailed Statistics screen fields
Field Description
MST ID Display the MST instances associated with the interface.
ifIndex The ifIndex of the interface table entry associated with this port on an
adapter
.
Port Type For normal ports this field is normal. Otherwise, the possible values are as
follows:
• Mirrored.
This port is a participating in port mirroring as a mirrored port.
Look at the Port Mirroring screens for more information.
• Probe.
This port is a participating in port mirroring as the probe port.
Look at the Port Mirroring screens for more information.
• T
runk Member. The port is a member of a link aggregation trunk. Look
at the Port Channel screens for more information.
