Manage Device Security
338
M4100 Series Managed Switch
4. Enter the IP address of the switch in the web browser address field.
The default IP address of the switch is 169.254.100.100.
The Login screen displays.
5. Enter the user name and password.
The default admin user name is admin and the default admin password is blank, that is,
do not enter a password.
6. Click the Login button.
The web management interface menu displays.
7. Select Security
Control > IP Source Guard Binding Configuration.To con
8. T
o configure static binding, specify the following:
a. Interface. Selects the interface to add a binding into the IPSG database.
b. Use MAC Address to specify the MAC address for the binding.
c. Use VLAN ID to select the VLAN from the list for the binding rule.
d. Use IP Address to specify valid IP address for the binding rule.
e. T
o add IPSG static binding entry into the database, click the ADD button.
f. T
o delete selected static entries from the database, click the DELETE button.
9. Click the CLEAR button to clear all the dynamic binding entries
The following table describes the nonconfigurable information displayed on the screen.
Table 91. Dynamic Binding Configuration
Field Description
Interface Displays the interface to add a binding into the IPSG database.
MAC Address Displays the MAC address for the binding entry.
VLAN ID Displays the VLAN from the list for the binding entry.
IP Address Displays valid IP address for the binding entry.
Filter Type Filter type used on the interface. One is source IP address filter type,
the other is source IP address and MAC address filter type.
