NETGEAR M4100 Series User Manual

Configure System Information
52
M4100 Series Managed Switch
3. Launch a web browser.
4. Enter the IP address of the switch in the web browser address field.
The default IP address of the switch is 169.254.100.100.
The Login screen displays.
5. Enter the user name and password.
The default admin user name is admin and the default admin password is blank, that is,
do not enter a password.
6. Click the Login button.
The web management interface menu displays.
7. Select System
 Management  Green Ethernet Green Ethernet Interface
Configuration.
8. Specify the Go To Interface by entering the Interface in unit/slot/port format and click the Go
button.
The entry corresponding to the specified Interface is selected.
9. Select the Port.
10. Use the Auto Power Down Mode selection to enable or disable this option.
The factory default is enable. When the port link is down the PHY automatically goes
down for short period of time, and then wakes up to check link pulses.
This allows
performing autonegotiation and saving power consumption when no link partner is
present.
11. Click the APPL
Y button.
The settings are sent to the switch. Configuration changes take effect immediately. These
changes are not retained across a power cycle unless you save the configuration. See
Save Configuration on page 405.

NETGEAR M4100 Series Specifications

General

Model	M4100 Series
Switch Type	Managed
Form Factor	Rack-mountable
Port Configuration	24 or 48 ports
Ethernet Ports	10/100/1000 Mbps
PoE Support	Available on some models (PoE and PoE+)
Layer	Layer 2/Layer 3
Management	Web-based, CLI, SNMP
VLAN Support	Yes
QoS	Yes
Stackable	Yes
Ports	24 or 48
Jumbo Frame Support	Yes
Security Features	ACL, 802.1X, RADIUS, TACACS+
Operating Temperature	0° to 50° C (32° to 122° F)
Storage Temperature	-20° to 70° C (-4° to 158° F)
Power Supply	Internal power supply
