Configure System Information
56
M4100 Series Managed Switch
The web management interface menu displays.
7. Select System
Management Green Ethernet Green Ethernet Summary.
Click the REFRESH button to refresh the screen with the most current data from the switch.
The following table describes the Green Mode Statistics Summary nonconfigurable fields.
Table 14. Green Mode Statistics Summary
Field Description
Current Power Consumption
(mW
atts)
Estimated power consumption by all ports in mWatts.
Percentage Power Saving (%) Percentage of power saved on all ports due to Green modes enabled.
Cumulative Energy Saving (W * H) Cumulative Energy saved in Watts * Hours due to all green modes
being enabled.
Unit Displays the Unit ID.
Green Features supported on this
unit
List of Green Features supported on the given unit, that could be one or
more of the following: Energy-Detect (Energy Detect), EEE (Energy
Ef
ficient Ethernet), LPI-History (EEE Low Power Idle History),
LLDP-Cap-Exchg (EEE LLDP Capability Exchange), Pwr-Usg-Est
(Power Usage Estimates).
Interface Interface for which data is displayed or configured.
