NETGEAR M4100 Series User Manual

Configure System Information
77
M4100 Series Managed Switch
7. Select System > PoE > Basic > PoE Configuration.
The Unit Selection list displays the current PoE unit.
8. T
o change the PoE unit, select another unit from the menu.
9. T
o set the System Usage Threshold, enter a number from 1 to 99.
This sets the threshold level at which a trap is sent if consumed power is greater than the
threshold power
.
10. Use Power Management Mode to describe or control the power management algorithm
used by the PSE to deliver power to the requesting PDs.
Select Static to indicate that the power allocated for each port depends on the type of
power threshold configured on the port. Select Dynamic to indicate that the power
consumption on each port is measured and calculated in real time.
11. Select the Traps Enable or Disable radio button.
Enable activates the PoE traps. Disable deactivates the PoE traps.
The default setting is
enabled.
12. Click the APPLY button.
The updated configuration is sent to the switch. Configuration changes take effect
immediately
.
The following table shows the nonconfigurable fields in the PoE Configuration screen.
Table 22. PoE Configuration
Field Description
Units Displays the Current PoE Unit. You can change the PoE Unit by
selecting another unit ID listed here.
Firmware Version Version of the PoE controller's FW image.

NETGEAR M4100 Series Specifications

General

Model	M4100 Series
Switch Type	Managed
Form Factor	Rack-mountable
Port Configuration	24 or 48 ports
Ethernet Ports	10/100/1000 Mbps
PoE Support	Available on some models (PoE and PoE+)
Layer	Layer 2/Layer 3
Management	Web-based, CLI, SNMP
VLAN Support	Yes
QoS	Yes
Stackable	Yes
Ports	24 or 48
Jumbo Frame Support	Yes
Security Features	ACL, 802.1X, RADIUS, TACACS+
Operating Temperature	0° to 50° C (32° to 122° F)
Storage Temperature	-20° to 70° C (-4° to 158° F)
Power Supply	Internal power supply
