Configure System Information
82
M4100 Series Managed Switch
12. Select the Power Limit to define the maximum power in watts that can be delivered by a
port.
13. The Detection Type describes a PD detection mechanism performed by the PSE port.
• pre-ieee. Only legacy detection is done.
• ieee. 4 Point Resistive Detection is done.
• auto. 4 Point Resistive Detection followed by Legacy Detection is done.
• 4point and Legacy indicates that the resistive 4 point detection scheme is used and
when it fails to detect a connected PD, legacy capacitive detection is used.
14. The Timer Schedule defines the timer schedule assigned to the port.
Select None to remove the timer schedule assignment.
15. Click Reset to forcibly reset the PSE port.
16. Click the APPLY button.
The updated configuration file is sent to the switch. Configuration changes take effect
immediately.
The following table describes the PoE Port Configuration nonconfigurable fields.
Table 24. PoE Port Configuration
Field Description
Port The interface.
High Power Enabled when particular port supports High Power Mode.
Max Power The maximum power in Watts that can be provided by the port.
Class The Class defines the range of power a PD is drawing from the system.
Class definitions:
0 – 0.44-12.95 (watts)
1 – 0.44-3.83 (watts)
2 – 0.44-6.48 (watts)
3 – 0.44-12.95 (watts)
4 – 0.44-25.5 (watts)
Output Voltage Current voltage being delivered to device in volts.
Output Current Current being delivered to device in mA.
Output Power Current power being delivered to device in Watts.
