Page #93 background imageLoading...
Page #93 background image
Configure System Information
93
M4100 Series Managed Switch
2. Connect an Ethernet cable from an Ethernet port on your computer to an Ethernet port on
the switch.
3. Launch a web browser
.
4. Enter the IP address of the switch in the web browser address field.
The default IP address of the switch is 169.254.100.100.
The Login screen displays.
5. Enter the user name and password.
The default admin user name is admin and the default admin password is blank, that is,
do not enter a password.
6. Click the Login button.
The web management interface menu displays.
7. Select System
LLDP Statistics.
The following table describes the LLDP Statistics fields.
Table 25. LLDP statistics
Field Description
Last Update Specifies the time when an entry was created, modified, or deleted in
the tables associated with the remote system.
Total Inserts Specifies the number of times the complete set of information
advertised by a particular MAC Service
Access Point (MSAP) was
inserted into tables associated with the remote systems.
