134 HVAC Drive H300
Issue Number: 3
* Only a value of 3 or 4 in this parameter is saved.
If Pr 00.033 is equal to 1 or 2, this value is not transferred to the
EEPROM or the drive. If Pr 00.033 is set to a 3 or 4 the value is
transferred.
For further information, please refer to section 9 NV Media Card
Operation on page 167.
Date (00.034), Time (00.035 and Day Of Week (00.036) show the date
and time as selected by Date/Time Selector (00.037). Date (00.034)
stores the date in dd.mm.yy format regardless of the setting made in
Date Format (00.038) however if the parameter is viewed using a
keypad the date will be displayed in the format selected in Date Format
(00.038). If a real time clock is selected from an option module then the
days, months and years are from the real time clock and the day of the
week is displayed in Day Of Week (00.036). Otherwise the days have a
minimum value of 0 and roll over after 30, the months have a minimum
value of 0 and roll over after 11, and Day Of Week (00.036) is always 0
(Sunday).
If when setting the date/time this parameter is being written via comms
or from and applications module then the value should be written in
standard dd/mm/yy format as described below.
The value of this parameter as seen over comms or to an applications
module is as follows.
Value = (day[1..31] x 10000) + (month[1..12] x 100) + year[0..99]
See Date (00.034)
See Date (00.034)
When the Date/Time Selector (00.037) = 0, the Date (00.034) and Time
(00.035) can be written by the user and the values in these parameters
are transferred to the real time clocks in the keypad or any option
modules that support this feature that are fitted to the drive. When Date/
Time Selector (00.037) is changed to any other value, the real time
clocks are allowed to run normally again. When Date/Time Selector
(00.037) is changed from any value to 0 the date and time from a real
time clock, if present, is automatically loaded into Date (00.034) and
Time (00.035), so that this date and time is used as the initial value for
editing. If more than one real time clock is present the date/time from the
keypad is used, if present, and if not then the date/time from the lowest
number slot with a real time clock is used.
Date (00.034) and Time (00.035) are used by the timers in Menu 09 and
for time stamping trips. These features will continue to use the originally
selected clock even if Date/Time Selector (00.037) is changed until a
drive reset is initiated. If Date/Time Selector (00.037) has been changed
and a reset is initiated Timer 1 Repeat Function (09.039
) and Timer 2
Repeat Function (09.049) are set to zero to disable the timers, and the
trip dates and times (00.060 to 00.079) are reset to zero.
Date / Time selector (00.037) is used to select the drive date and time as
shown in the table below.
00.033 {11.042} Parameter Cloning
RW Txt NC US
OL
Ú
None (0), Read (1),
Program (2),
Auto (3), Boot (4)
Ö
None (0)RFC-A
RFC-S
Pr
String
Pr
value
Comment
None 0 Inactive
Read 1 Read parameter set from the NV Media Card
Program 2
Programming a parameter set to the NV Media
Card
Auto 3 Auto save
Boot 4 Boot mode
00.034 {06.016} Date
RW Date ND NC PT
OL
Ú
00-00-00 to 31-12-99
Ö
RFC-A
RFC-S
00.035 {06.017} Time
RW Time ND NC PT
OL
Ú
00:00:00 to 23:59:59
Ö
RFC-A
RFC-S
NOTE
00.036 {06.018} Day of Week
RO Txt ND NC PT
OL
Ú
Sunday (0), Monday (1),
Tuesday (2), Wednesday (3),
Thursday (4), Friday (5),
Saturday (6)
Ö
RFC-A
RFC-S
00.037 {06.019} Date / Time Selector
RW Txt US
OL
Ú
Set (0), Powered (1), Running (2),
Acc Powered (3), Local Keypad (4),
Remote Keypad (5), Slot 1 (6),
Slot 2 (7), Slot 3 (8), Slot 4 (9)
Ö
Local keypad (4)RFC-A
RFC-S
Date/Time
Selector (06.019)
Date/Time Source
0: Set
Date and time parameters can be written by the
user.
1: Power Time since the drive was powered up.
2: Running
Accumulated drive running time since the drive
was manufactured.
3: Acc Power
Accumulated powered-up time since the drive
was manufactured.
4: Local Keypad
If a keypad fitted to the front of the drive includes
a real time clock, then the date/time from this
clock is displayed, otherwise the date/time is set
to zero.
5: Remote Keypad
If a keypad connected to the user comms port of
the drive with a EIA-485 includes a real time
clock, then the date/time from this clock is
displayed, otherwise the date/time is set to zero.
6: Slot 1 As 4 above, but for option slot 1.
7: Slot 2 As 4 above, but for option slot 2.
8: Slot 3 As 4 above, but for option slot 3.
9: Slot 4 As 4 above, but for option slot 4.
