Figure 3-25 Through panel mounting the size 4 drive
Figure 3-26 Through panel mounting the size 5 drive
106 mm (4.17 in)
17 mm
(0.67 in)
394 mm (15.51 in)
401 mm (15.79 in)
124 mm (4.88 in)
134 mm (5.28 in)
68.5 mm
(2.70 in)
68.5 mm
(2.70 in)
117 mm (4.61 in)
168 mm (6.61 in)
67 mm
(2.64 in)
58.5 mm
(2.30 in)
58.5 mm
(2.30 in)
78
106 mm (4.17 in)
156 mm (6.14 in)
359 mm (14.13 in)
169 mm (6.65 in)
26 mm
(1.02 in)
167 mm (6.58 in)
26 mm
(1.02 in)
393 mm (15.47 in)
137 mm (5.39 in)
Æ6.5 mm (0.3 in)
(x 4 holes)
Æ5.2 mm (0.20 in)
(x 4 holes)
143 mm (5.63 in)
409 mm (16.10 in)
365 mm (14.37 in)
135 mm (5.32 in)
67 mm (2.64 in)
17 mm
(0.66 in)
53 mm (2.1 in) 53 mm (2.1 in)
78 mm (3.07 in) 78 mm (3.07 in)
68.5 mm (2.70 in)
68.5 mm (2.70 in)
Radius 1.0 mm
(0.04 in)
