264 HVAC Drive H300
Issue Number: 3
12.1.2 Power dissipation
Table 12-4 Losses @ 40° C (104° F) ambient
Model
Normal Duty
Nominal rating Drive losses (W) taking into account any current derating for the given conditions
kW hp
2
kHz
3
kHz
4
kHz
6
kHz
8
kHz
12
kHz
16
kHz
200 V
03200066 1.1 1.5 88 93 95 99 104 113 122
03200080 1.5 2 95 100 102 107 113 122 133
03200110 2.2 3 117 123 126 133 139 151 146
03200127 3 3 129 136 141 149 158 168 157
04200180 4 5 171 180 187 201 216 244 273
04200250 5.5 7.5 227 239 248 266 284 308 314
05200300 7.5 10 280 291 302 324 344 356 342
06200500 11 15 375 394 413 452 490 480 485
06200580 15 20 442 463 484 528 522 481 486
07200750 18.5 25 533 570 597 650 703 885 894
07200940 22 30 671 718 751 815 881 890 899
07201170 30 40 851 911 951 1004 911 920 929
08201490 37 50 1339 1433 1536 1765 1943 1962 1982
08201800 45 60 1638 1753 1894 1914 1985 2005 2025
09202160 (9A) 55 75 2028 2170 2312 2596 2448 2160 2031
09202660 (9A) 75 100 2585 2754 2822 2623 2448 2156 2034
09202160 (9E) 55 75 1889 2031 2174 2458 2348 2112 2006
09202660 (9E) 75 100 2375 2554 2625 2482 2348 2108 2009
10203250 90 125 2478 2672 2867 3123 2952 2701 2554
10203600 110 150 2802 3016 3230 3126 2957 2706 2554
400 V
03400034 1.1 1.5 76 80 84 94 103 123 141
03400045 1.5 2 84 88 92 104 115 137 160
03400062 2.2 3 99 104 112 125 139 167 157
03400077 3 5 108 114 122 137 153 149 147
03400104 4 5 138 145 158 186 212 201 197
03400123 5 7.5 155 163 179 209 208 201 200
04400185 7.5 10 214 225 244 283 322 325 310
04400240 11 15 269 283 307 325 329 325 315
05400300 15 20 295 324 353 356 355 359 362
06400380 18.5 25 378 417 456 532 613 652 645
06400480 22 30 469 515 561 657 651 646 650
06400630 30 40 616 656 659 650 646 643 649
07400790 37 50 745 830 907 1062 1218 1230 1242
07400940 45 60 896 999 1088 1264 1241 1253 1266
07401120 55 75 1033 1152 1247 1218 1170 1182 1194
08401550 75 100 1482 1652 1817 2154 2121 2142 2164
08401840 90 125 1798 2004 2191 2333 2279 2302 2325
09402210 (9A) 110 150 2431 2710 2989 3075 2992 2842 2833
09402660 (9A) 132 200 3016 3191 3143 3063 3000 2856 2828
09402210 (9E) 110 150 2286 2565 2844 2966 2917 2807 2815
09402660 (9E) 132 200 2806 2998 2984 2955 2925 2821 2811
10403200 160 250 3210 3582 3954 4148 4034 3939 3843
10403610 200 300 3703 4121 4226 4154 4038 3947 3874
11404370 225 350 4182 4576 4708 4444 4246
11404870 250 400 4734 4843 4708 4444 4246
11405070 280 400 4962 4843 4708 4444 4246
