Table 10-21 Binary input objects
Table 10-22 Binary output objects
To control a binary output via BACnet the source parameter for the output must be set to a read/write bit parameter on menu 18. (Pr 18.031 to
Pr 18.050 are acceptable).
Table 10-23 Binary value objects
* Filter change required / done (Pr 06.022) can only be set to inactive (Boolean FALSE)
**Drive reset (Pr 10.033) will be initiated when set from inactive (Boolean FALSE) to active (Boolean TRUE)
Object ID (BIn) Object name Description
Present value access
mode
1 Drive binary input 1 Digital input 1 on drive (bi-dir Pr 08.001)RO
2 Drive binary input 2 Digital input 2 on drive (bi-dir Pr 08.002)RO
3 Drive binary input 3 Digital input 3 on drive (bi-dir Pr 08.003)RO
4 Drive binary input 4
Digital input 4 on drive
(bi-dir Pr 08.004)
RO
5 Drive binary input 5
Digital input 5 on drive
(bi-dir Pr 08.005)
RO
6 Drive binary input 6
Digital input 6 on drive
(bi-dir Pr 08.006)
RO
7 Drive binary input 7
Drive enable input
(Pr 08.009)
RO
Object ID (BOn) Object name Description
Present value
access mode
1 Drive binary output 1 Digital output 1 on drive (bi-dir Pr 08.001)C
2 Drive binary output 2 Digital output 2 on drive (bi-dir Pr 08.002)C
3 Drive binary output 3 Digital output 3 on drive (bi-dir Pr 08.003)C
4 Drive binary output 4 24V Output (Pr 08.008)C
5 Drive binary relay 1 Drive relay 1 (Pr 08.007)C
6 Drive binary relay 2 Drive relay 2 (Pr 08.045)C
Object ID (BVn) Object name Description
Present value
access mode
1 Reset energy meter
Reset drive energy meter
(Pr 06.024)
RW
2 Filter change required Filter change required/done (Pr 06.022)RW*
3 Drive run forward Run forward (Pr 06.030)C
4 Drive Heathy Drive Heathy indication (Pr 10.001)RO
5 Drive warning
Drive warning/alarm state
(Pr 10.019)
RO
6 Drive reset Drive reset (Pr 10.033)RW**
