12.2.3 EMC filter torque settings
Table 12-52 Optional external EMC Filter terminal data
CT part
number
Power
connections
Ground
connections
Bar hole diameter
Max cable
size
Max torque Ground stud size Max torque
4200-1132
N/A
50 mm
2
(1/0 AWG)
8.0 N m
(6.0lb ft)
M10
18 N m
(13.3 lb ft)
4200-0672
4200-1972
95 mm
2
(3/0 AWG)
20 N m
(14.8 lb ft)
4200-1662
4200-0122
16 mm
2
(6 AWG)
2.3 N m
(1.7 lb ft)
M6
4.8 N m
(2.8 lb ft)
4200-0252
1.8 N m
(1.4 lb ft)
4200-0272
4200-0312
4200-0402
4200-3230
4 mm
2
(12 AWG)
0.8 N m
(0.59 lb ft)
M5
3.0 N m
(2.2 lb ft)
4200-3480
4 mm
2
(12 AWG)
0.8 N m
(0.59 lb ft)
M5
4200-2300
16 mm
2
(6 AWG)
2.3 N m
(1.70 Ib ft)
M6
4.8 N m
(2.8 lb ft)
4200-4800
4200-3690
4200-3021 10.8 mm
N/A 30 N m (22.1 lb ft)
M10
18 N m
(13.3 lb ft)
4200-4460 11 mm
4200-1660 10.8 mm
4200-2210 11 mm
4200-0400 10.5 mm
M12
25 N m
(18.4 lb ft)
4200-0690 10.5 mm
