4.2.3 Drive model and input line reactor
Table 4-2 Drive model and line reactor part number
* Natural cooling.
** May represent a more economic solution when operating below 420 A.
Size Drive model Inductor model Line reactor part number
3
03200066, 03200080 INL 2001 4401-0143
03200110, 03200127 INL 2002 4401-0144
03400034, 03400045 INL 4001 4401-0148
03400062 INL 4002 4401-0149
03400077, 03400104 INL 4011 4401-0234
03400123 INL 4003 4401-0151
4
04200180 INL 2002 4401-0144
04200250 INL 2003 4401-0145
04400185 INL 4004 4401-0152
04400240 INL 4005 4401-0153
5
05200300 INL 2008 4401-0226
05400300 INL 4013 4401-0236
05500039 INL 5007 4401-0242
05500061 INL 5008 4401-0243
05500100 INL 5009 4401-0244
6
06200500 INL 2004 4401-0146
06200580 INL 2005 4401-0147
06400380 INL 4006 4401-0154
06400480 INL 4007 4401-0155
06400630 INL 4008 4401-0156
06500120 INL 5001 4401-0157
06500170 INL 5002 4401-0158
06500220 INL 5003 4401-0159
06500270 INL 5004 4401-0160
06500340 INL 5005 4401-0161
06500430 INL 5006 4401-0223
7
07200750 INL 2009 4401-0227
07200940 INL 2010 4401-0228
07201170 INL 2011 4401-0229
07400790 INL 4014 4401-0237
07400940 INL 4015 4401-0238
07401120 INL 4016 4401-0239
07500530 INL 5006 4401-0223
07500730 INL 5010 4401-0245
07600230 INL 6001 4401-0248
07600300 INL 6002 4401-0249
07600360 INL 6003 4401-0250
07600460 INL 6004 4401-0251
07600520 INL 6005 4401-0252
07600730 INL 6006 4401-0253
8
08201490 INL 2012 4401-0230
08201800 INL 2013 4401-0231
08401550 INL 4017 4401-0240
08401840 INL 4018 4401-0241
08500860 INL 5011 4401-0246
08501080 INL 5012 4401-0247
08600860 INL 6007 4401-0254
08601080 INL 6008 4401-0255
9E
09202160, 09202660, 09402210, 09402660 INL 401 4401-0181
09501250, 09501500, 09601720, 09601970 INL 601 4401-0183
10E
10203250, 10203600, 10403200, 10403610 INL 402 4401-0182
10502000, 10601720, 10601970 INL 602 4401-0184
11E
11404370 INL 403L** 4401-0274
11404370, 11404870, 11405070 INL 403* 4401-0259
11502480, 11502880, 11503150, 11602250, 11602750, 11603050 INL 603* 4401-0261
