284 HVAC Drive H300
Issue Number: 3
12.2.1 EMC filter ratings
Table 12-50 Optional external EMC filter details
12.2.2 Overall EMC filter dimensions
Table 12-51 Optional external EMC filter dimensions
CT part
number
Maximum
continuous current
Voltage rating
IP rating
Power dissipation at
rated current
Ground leakage
Discharge
resistors
Balanced supply
phase-to-phase
and
phase-to-ground
Worst case@ 40 °C
(104 °F)
@ 50 °C
(122 °F)
IEC UL
@ 40 °C
(104 °F)
@ 50 °C
(122 °F)
AAVV WWmAmAMΩ
4200-3230 20 18.5 250 300
20
20 17 2.4 60
1.68
4200-0272 27 24.8 250 300 33 28 6.8 137
4200-0312 31 28.5 250 300 20 17 2.0 80
4200-2300 55 51 250 300 41 35 4.2 69
4200-3480 16 15 528 600 13 11 10.7 151
4200-0252 25 23 528 600 28 24 11.1 182
4200-0402 40 36.8 528 600 47 40 18.7 197
4200-4800 63 58 528 600 54 46 11.2 183
4200-0122 12 11 760 600
4200-3690 42 39 760 600 45 39 12 234
CT part
number
Dimension (mm)
Weight
HWD
mm inch mm inch mm inch kg lb
4200-3230 426 16.77 83 3.27 41 1.61 1.9 4.20
4200-0272 437 17.20 123 4.84 60 2.36 4.0 8.82
4200-0312 437 17.20 143 5.63 60 2.36 5.5 12.13
4200-2300 434 17.09 210 8.27 60 2.36 6.5 14.30
4200-3480 426 16.77 83 3.27 41 1.61 2.0 4.40
4200-0252 437 17.20 123 4.84 60 2.36 4.1 9.04
4200-0402 437 17.20 143 5.63 60 2.36 5.5 12.13
4200-4800 434 17.09 210 8.27 60 2.36 6.7 14.80
4200-0122 437 17.20 143 5.63 60 2.36 5.5 12.13
4200-3690 434 17.09 210 8.27 60 2.36 7.0 15.40
4200-1132 270 10.63 90 3.54 205 5.9 6.0 13.20
4200-0672 270 10.63 90 3.54 205 5.9 6.2 13.70
4200-1972 300 11.81 120 4.72 170 6.69 9.6 21.10
4200-1662 270 10.63 90 3.54 205 8.07 9.4 20.70
4200-3021 339 13.34 230 9.06 120 4.72 11 24.25
4200-4460 105 4.13 360 14.2 245 9.65 12 26.50
4200-0400 135 5.32 386 15.2 260 10.2 14.7 32.41
4200-1660 360 14.7 245 9.65 105 4.13 5.2 11.46
4200-2210 105 4.13 360 14.2 245 9.65 10.3 22.71
4200-0690 135 5.32 386 15.2 260 10.2 16.75 36.90
