3.10 External EMC filter
.
The external EMCfilter details for each drive rating are provided in the table below.
Table 3-9 External EMC filter data
Model CT part number
Weight
kg Ib
200 V
03200066 to 03200127 4200-3230 1.9 4.20
04200180 to 04200250 4200-0272 4.0 8.82
05200300 4200-0312 5.5 12.13
06200500 to 06200580 4200-2300 6.5 14.3
07200750 to 07201170 4200-1132 6 13.2
08201490 to 08201800 4200-1972 9.6 21.1
09202160 to 09202660 (9A) 4200-3021 11 24.3
09202160 to 09202660 (9E) 4200-4460 12 26.5
10203250 to 10203600 4200-4460 12 26.5
400 V
03400034 to 03400123 4200-3480 2.0 4.40
04400185 to 04400240 4200-0252 4.1 9.04
05400300 4200-0402 5.5 12.13
06400380 to 06400630 4200-4800 6.7 14.8
07400790 to 07401120 4200-1132 6 13.2
08401550 to 08401840 4200-1972 9.6 21.1
09402210 to 09402660 (9A) 4200-3021 11 24.25
09402210 to 09402660 (9E) 4200-4460 12 26.5
10403200 to 10403610 4200-4460 12 26.5
11404370 to 11405070 4200-0400 14.7 32.41
575 V
05500039 to 05500100 4200-0122 5.5 12.13
06500120 to 06500430 4200-3690 7.0 15.4
07500530 to 07500730 4200-0672 6.2 13.7
08500860 to 08501080 4200-1662 9.4 20.7
09501250 to 09501500 (9A) 4200-1660 5.2 11.46
09501250 to 09501500 (9E) 4200-2210 10.3 22.7
10502000 4200-2210 10.3 22.7
11502480 to 11503150 4200-0690 16.75 36.9
690 V
07600230 to 07600730 4200-0672 6 13.2
08600860 to 08601080 4200-1662 9.4 20.7
09601250 to 09601550 (9A) 4200-1660 5.2 11.5
09601250 to 09601550 (9E) 4200-2210 10.3 22.7
10601720 to 10601970 4200-2210 10.3 22.7
11602250 to 11603050 4200-0690 16.75 36.9
