14 HVAC Drive H300
Issue Number: 3
Table 2-2 400 V drive ratings (380 V to 480 V ±10 %)
* These ratings are for 2 kHz switching frequency. For ratings at 3 kHz switching frequency refer to Chapter 12.1.1 Power and current ratings
(Derating for switching frequency and temperature) on page 259.
Model
Normal Duty
Maximum continuous
output current
Nominal power
at 400 V
Motor power
at 460 V
Peak current
AkWhpA
Frame size 3
03400034 3.4 1.1 1.5 3.7
03400045 4.5 1.5 2.0 4.9
03400062 6.2 2.2 3.0 6.8
03400077 7.7 3.0 5.0 8.4
03400104 10.4 4.0 5.0 11.4
03400123 12.3 5.5 7.5 13.5
Frame size 4
04400185 18.5 7.5 10.0 20.3
04400240 24.0 11.0 15.0 26.4
Frame size 5 05400300 30.0 15.0 20.0 33.0
Frame size 6
06400380 38.0 18.5 25.0 41.8
06400480 48.0 22.0 30.0 52.8
06400630 63.0 30.0 40.0 69.3
Frame size 7
07400790 79 37 50 86.9
07400940 94 45 60 103.4
07401120 112 55 75 123.2
Frame size 8
08401550 155 75 100 170.5
08401840 184 90 125 202.4
Frame size 9
09402210 221 110 150 243.1
09402660 266* 132 200 292.6
Frame size 10
10403200 320 160 250 352
10403610 361 200 300 397.1
Frame size 11
11404370 437 225 350 480.7
11404870 487* 250 400 535.7
11405070 507* 280 450 557.7
