220 HVAC Drive H300
Issue Number: 3
Parameter
Range(
Ú)Default(Ö)
Type
OL RFC-A / S OL RFC-A RFC-S
04.001 Current Magnitude 0.000 to VM_DRIVE_CURRENT_UNIPOLAR A RO Num ND NC PT FI
04.002 Torque Producing Current / lq VM_DRIVE_CURRENT A RO Num ND NC PT FI
04.003 Final Torque Reference VM_TORQUE_CURRENT %
RO Num ND NC PT FI
04.004 Final Current Reference VM_TORQUE_CURRENT %
RO Num ND NC PT FI
04.005 Motoring Current Limit 0.0 to VM_MOTOR1_CURRENT_LIMIT % 110.0 % RW Num RA US
04.006 Regenerating Current Limit 0.0 to VM_MOTOR1_CURRENT_LIMIT % 110.0 % RW Num RA US
04.007 Symmetrical Current Limit 0.0 to VM_MOTOR1_CURRENT_LIMIT % 110.0 % RW Num RA US
04.012 Current Reference Filter 1 Time Constant 0.0 to 25.0 ms 1.0 ms RW Num US
04.013 Current Controller Kp Gain 0 to 30000 20 150 RW Num US
04.014 Current Controller Ki Gain 0 to 30000 40 2000 RW Num US
04.015 Motor Thermal Time Constant 1 1.0 to 3000.0 s 89.0 s RW Num US
04.016 Thermal Protection Mode 00 to 11 00 RW Bin US
04.017 Magnetising Current / ld VM_DRIVE_CURRENT A RO Num ND NC PT FI
04.018 Final Current Limit VM_TORQUE_CURRENT % RO Num ND NC PT
04.019 Motor Protection Accumulator 0.0 to 100.0 % RO Num ND NC PT PS
04.020 Percentage Load VM_USER_CURRENT % RO Num ND NC PT FI
04.021 Current feedback filter disable Off (0) or On (1) Off (0) RW Bit US
04.024 User Current Maximum Scaling 0.0 to VM_TORQUE_CURRENT_UNIPOLAR 110.0 % RW Num RA US
04.025 Low Speed Thermal Protection Mode 0 to 1 0 RW Num US
04.026 Percentage Torque 0.0 to VM_USER_CURRENT % RO Num ND NC PT FI
04.027 Low load detection level 0.0 to100% 0.0 % RW Num US
04.028 Low load detection speed / frequency threshold VM_SPEED_FREQ_REF_UNIPOLAR 0.0 Hz 0.0 rpm RW Num US
04.029 Enable trip on low load Off (0) or On (1) Off (0) RW Bit US
04.036 Motor Protection Accumulator Power-Up Value Power down (0), Zero (1), Real time (2) Power down (0) RW Txt US
04.037 Motor Thermal Time Constant 2 1.0 to 3000.0 s 89.0 s RW Num US
04.038 Motor Thermal Time Constant 2 Scaling 0 to 100 % 0 % RW Num US
04.039 Rated Iron Losses As Percentage Of Losses 0 to 100 % 0 % RW Num US
04.041 Rated Torque 0.00 to 50000.00 Nm 0.00 Nm RW Num US
04.049 Magnetising Current Limit 0.0 to 100.0 % 100.0 % RW Num US
RW Read / Write RO Read only Num Number parameter Bit Bit parameter Txt Text string Bin Binary parameter FI Filtered
ND No default value NC Not copied PT Protected parameter RA Rating dependent US User save PS Power-down save DE Destination
