HVAC Drive H300 23
Issue Number: 3
Table 2-10 Parts supplied with the drive (size 9A, 9E, 10E and 11E)
Description Size 9A / 9E Size 10E Size 11E
Control connectors
1 to 9 and 21 to 29
x 1 x 1
Relay connector
x 1 x 1
24 V power supply connectors
x 1 x 1
Grounding bracket
x 1
Surface mounting brackets
x 2
x 2
x 1
