230 HVAC Drive H300
Issue Number: 3
Parameter
Range(
Ú)Default(Ö)
Type
OL RFC-A / S OL RFC-A RFC-S
07.001 Analog Input 1 ±100.00 % RO Num ND NC PT FI
07.002 Analog Input 2 ±100.00 % RO Num ND NC PT FI
07.004 Monitored Temperature 1 ±250 °C
RO Num ND NC PT
07.005 Monitored Temperature 2 ±250 °C RO Num ND NC PT
07.006 Monitored Temperature 3 ±250 °C RO Num ND NC PT
07.007 Analog Input 1 Mode
4-20 mA Low (-4), 20-4 mA Low (-3), 4-20 mA Hold (-2),
20-4 mA Hold (-1), 0-20 mA (0), 20-0 mA (1),
4-20 mA Trip (2), 20-4 mA Trip (3), 4-20 mA (4),
20-4 mA (5), Volt (6), Therm Short Cct (7), Thermistor (8),
Therm No Trip (9)
4-20 mA (4) RW Txt US
07.008 Analog Input 1 Scaling 0.000 to 10.000 1.000 RW Num US
07.009 Analog Input 1 Invert Off (0) or On (1) Off (0) RW Bit US
07.010 Analog Input 1 Destination 0.000 to 59.999 1.036 RW Num DE PT US
07.011 Analog Input 2 Mode
4-20 mA Low (-4), 20-4 mA Low (-3), 4-20 mA Hold (-2),
20-4 mA Hold (-1), 0-20 mA (0), 20-0 mA (1),
4-20 mA Trip (2), 20-4 mA Trip (3), 4-20 mA (4),
20-4 mA (5), Volt (6), Therm Short Cct (7), Thermistor (8),
Therm No Trip (9)
Volt (6) RW Txt US
07.012 Analog Input 2 Scaling 0.000 to 10.000 1.000 RW Num US
07.013 Analog Input 2 Invert Off (0) or On (1) Off (0) RW Bit US
07.014 Analog Input 2 Destination 0.000 to 59.999 1.037 RW Num DE PT US
07.019 Analog Output 1 Source 0.000 to 59.999 5.001 3.002 RW Num PT US
07.020 Analog Output 1 Scaling 0.000 to 10.000 1.000 RW Num US
07.021 Analog Output 1 Mode
Volts (0), 0-20 mA (1), 20-0 mA (2),
4-20 mA (3), 20-4 mA (4)
Volts (0) RW Txt US
07.022 Analog Output 2 Source 0.000 to 59.999 4.002 RW Num PT US
07.023 Analog Output 2 Scaling 0.000 to 10.000 1.000 RW Num US
07.024 Analog Output 2 Mode
Volts (0), 0-20 mA (1), 20-0 mA (2), 4-20 mA (3),
20-4 mA (4)
Volts (0) RW Txt US
07.025 Calibrate Analog Input 1 Full Scale Off (0) or On (1) Off (0) RW Bit NC
07.026 Analog Input 1 Fast Update Active Off (0) or On (1)
RO Bit ND NC PT
07.027 Analog Input 1 Fast Update Active Off (0) or On (1) RO Bit ND NC PT
07.028 Analog Input 1 Current Loop Loss Off (0) or On (1) RO Bit ND NC PT
07.029 Analog Input 2 Current Loop Loss Off (0) or On (1) RO Bit ND NC PT
07.030 Analog Input 1 Offset ±100.00 % 0.00 % RW Num US
07.031 Analog Input 2 Offset ±100.00 % 0.00 % RW Num US
07.033 Power Output ±100.0 % RO Num ND NC PT
07.034 Inverter Temperature ±250 °C RO Num ND NC PT
07.035 Percentage Of d.c. Bus Thermal Trip Level 0 to 100 % RO Num ND NC PT
07.036 Percentage Of Drive Thermal Trip Level 0 to 100 % RO Num ND NC PT
07.037 Temperature Nearest To Trip Level 0 to 29999 RO Num ND NC PT
07.038 Temperature Monitor Select 1 0 to 1999 1001 RW Num US
07.039 Temperature Monitor Select 2 0 to 1999 1002 RW Num US
07.040 Analog Input 1 Minimum ±100.00 % -100.00 % RW Num US
07.041 Analog Input 2 Minimum ±100.00 % -100.00 % RW Num US
07.043 Analog Input 1 Maximum ±100.00 % 100.00 % RW Num US
07.044 Analog Input 2 Maximum ±100.00 % 100.00 % RW Num US
07.051 Analog Input 1 Full Scale 0 to 65535 RO Num ND NC PT PS
07.052 Temperature Monitor Select 3 0 to 1999 1 RW Num US
07.053 Analog Input 1 Thermistor Type
DIN44082 (0), KTY84 (1),
PT100 (2), PT1000 (3),
PT2000 (4), NI1000 (5)
DIN44082 (0) RW Txt US
07.054 Analog Input 1 Thermistor Feedback 0 to 5000 Ω RO Num ND NC PT
07.055 Analog Input 1 Thermistor Trip Threshold 0 to 5000 Ω 3300 Ω RW Num US
07.056 Analog Input 1 Thermistor Reset Threshold 0 to 5000 Ω 1800 Ω RW Num US
07.057 Analog Input 1 Thermistor Temperature -50 to 300 °C RO Num ND NC PT
07.058 Analog Input 2 Thermistor Type
DIN44082 (0), KTY84 (1),
PT100 (2), PT1000 (3),
PT2000 (4), NI1000 (5)
DIN44082 (0) RW Txt US
07.059 Analog Input 2 Thermistor Feedback 0 to 5000 Ω RO Num ND NC PT
07.060 Analog Input 2 Thermistor Trip Threshold 0 to 5000 Ω 3300 Ω RW Num US
07.061 Analog Input 2 Thermistor Reset Threshold 0 to 5000 Ω 1800 Ω RW Num US
07.062 Analog Input 2 Thermistor Temperature -50 to 300 °C RO Num ND NC PT
RW Read / Write RO Read only Num Number parameter Bit Bit parameter Txt Text string Bin Binary parameter FI Filtered
ND No default value NC Not copied PT Protected parameter RA Rating dependent US User save PS Power-down save DE Destination
