268 HVAC Drive H300
Issue Number: 3
10403610 3482 3598 3676 3776 3694 3625 3589
11404370 4182 4329 4228 3988 3843
11404870 4456 4329 4228 3988 3843
11405070 4456 4329 4228 3988 3843
575 V
05500039 82 92 102 121 142 183 223
05500061 120 135 150 180 209 269 328
05500100 173 194 215 260 302 388 474
06500120 191 215 239 287 334 430 525
06500170 253 284 315 376 438 563 515
06500220 325 362 399 482 569 500 519
06500270 391 448 505 596 612 613 652
06500340 534 623 712 737 737 747 749
06500430 675 774 763 734 742 748 750
07500530 936 988 1115 1225 1144 1155 1167
07500730 1161 1225 1228 1098 1030 1040 1051
08500860 1753 1850 2172 2540 2672 2699 2726
08501080 1980 2090 2291 2540 2684 2711 2738
09501250 (9A) 1707 1977 2247 2538 2456 2495 2699
09501500 (9A) 2087 2410 2734 2544 2456 2482 2676
09501250 (9E) 1595 1865 2135 2443 2392 2460 2674
09501500 (9E) 1933 2256 2580 2448 2392 2447 2652
10502000 2692 2841 2654 2448 2392 2447 2652
11502480 3191 3678 3532
11502880 3965 3678 3532
11503150 3965 3678 3632
690 V
07600230 359 428 491 617 743 750 758
07600300 463 551 631 791 958 968 977
07600360 554 660 754 944 1144 1155 1167
07600460 717 854 965 1206 1144 1155 1167
07600520 814 969 1094 1225 1144 1155 1167
07600730 1029 1225 1228 1098 1030 1040 1051
08600860 1553 1850 2172 2540 2672 2699 2726
08601080 1755 2090 2291 2540 2684 2711 2738
09601250 (9A) 1878 2213 2548 2933 2882 2974 3248
09601550 (9A) 2384 2797 3175 2918 2855 2974 3249
09601250 (9E) 1730 2065 2400 2810 2803 2934 3223
09601550 (9E) 2160 2573 2955 2796 2778 2934 3225
10601720 2420 2882 2947 2805 2789 2932 3229
10601970 2614 3132 3610 3243 3221 3420 3771
11602250 3225 3893 4048
11602750 4023 4186 4048
11603050 4421 4230 4091
Model
Normal Duty
Drive losses (W) taking into account any current derating for the given conditions
2 kHz 3 kHz 4 kHz 6 kHz 8 kHz 12 kHz 16 kHz
