Table 12-29 Plug-in terminal block maximum cable sizes
Model size Terminal block description Max cable size
All
11 way control connectors
1.5 mm
2
(16 AWG)
2 way relay connector
2.5 mm
2
(12 AWG)
3
6 way AC power connector
6 mm
2
(10 AWG)
4
5
3 way AC power connector
3 way motor connector
8 mm
2
(8 AWG)
6
2 way low voltage power
24 V supply connector
1.5 mm
2
(16 AWG)
7
8
9A/9E
10E/11E
