Technical Notes
Attaching a Power Connector and AC Adapter
Turn the camera off before attaching an optional power
connector and AC adapter.
1
Open the battery-
chamber (
q
) and
power connector (
w
)
covers.
2
Insert the EP-5B power
connector.
•
Be sure to insert the connector in
the correct orientation.
•
Using the connector to keep the
orange battery latch pressed to one
side, slide the connector into the
battery chamber until the latch
locks the connector in place.
