ACCESS GATEWAY
System Administration 163
7. In the Username field, enter a user name for this subscriber. If you entered a MAC
address and you do not want to assign a user name, skip Step 9 (password).
8. If you assigned a user name, you must now assign a Password.
9. In the Expiration Time field, define the duration (in hours and minutes) for the
subscriber’s authorized access time. When the assigned time expires, the subscriber must
“re-subscribe” to the service.
10. Enter an amount in the Paid field.
11. The next two fields (User Definable 1 and User Definable 2) are optional. Use these
fields for simple notations about the subscriber.
12. Define the Max Upstream Bandwidth and Max Downstream Bandwidth range for this
subscriber (in Kbps).
13. Select a policy from the QoS Policy menu. See “Setting up Quality of Service {QoS}” on
page 109 for more information.
14. Enable Countdown after login if you want the timeout amount to take effect after the user
logins. If the option is not enabled, user timeouts take effect the moment the subscriber is
added.
15. Enable STMP Redirection to allow the specified user to have their SMTP traffic
redirected by the global SMTP redirect configuration.
16. Click on the Add button to add this subscriber to the database, or click on the Reset button
if you want to reset all the values to their previous state.
User names and passwords are case-sensitive. Having a user name and password
is an optional service that subscribers may request (for example, if they are using
more than one machine, or moving between locations and they want an additional
level of security). If they request this service, they are prompted at the login
screen for the user name and password you assign here. Solution providers can
charge a fee for this service, at their discretion.
