Purge Manifold and Pneumatics
Purge Manifold Assembly
See Figure 9-8. Quantities listed as As Required are dependent on the
number of purge manifolds.
Item Part Description Quantity Note
1 1100045 Cylinder, air, 40 x 160, Festo 1 A
2 1103505 Switch, cylinder proximity 2
3 1103935 Bracket, sensor, Festo DSEU40 2
4 −−−−−− Adapter, cylinder to clevis 1
5 −−−−−− Pin, roll, M10 x 40 1
6 −−−−−− Screw, set, M6 x 6, cup, steel 1
7 −−−−−− Clevis, cylinder, 12mm, Festo 2
8 1103934 Fitting, flow control, 1/8G 2
9 −−−−−− Manifold, purge, global PFC AR
10 1100024
S Quad ring, 208 silicone
9
11 1100023
S Guide, lance, global PFC
2
12 −−−−−− Screw, flat head, M8 x 16 mm, black 4
13 1100036 Bearing, 14 mm, plain, flanged 4
14 −−−−−− Lever, purge lock, Spectrum PFC 2
15 1100025 Latch, complete, 890N, modified AR
16 1100028
S Pawl, latch, global PFC
AR
17 −−−−−− Shaft, 8 mm hex, 3 manifold 2
18 −−−−−− Screw, button head, socket, M5 x 10, zinc AR
19 −−−−−− Screw, socket, M8 x 40, zinc, full thread 4
20 −−−−−− Washer, flat, regular, M8, steel, zinc 4
21 −−−−−− Sleeve, spacing, manifold plate 4
22 −−−−−− Screw, socket, M8 x 16mm, zinc AR
23 −−−−−− Spacer, purge bracket, dampening 4
24 −−−−−− Elbow, push in, 0.50 RPT x 16 mm tube AR
25 −−−−−− Washer, lock, internal/external tooth, 5/16 in. AR
26 −−−−−− Screw, pan, slotted, M5 x 20, brass 2
27 −−−−−− Washer, lock, external, M5, steel, zinc 4
28 −−−−−− Tag, ground 2
29 1034207 Jumper, ground, 12 in. 1
30 −−−−−− Washer, flat, M5, brass 4
NOTE A: Cylinder only.
AR: As Required
