Repair
8-16
Part 1602966−05
E 2015 Nordson Corporation
Vibratory Table Motor Weight Adjustment
Refer to Table 8-1. If you replace the vibratory table motor, or retrofit a
motor to the table, you will need to adjust the new motor weights to the
specified setting. Use the applicable instruction to adjust the weights.
Table 8-1 Table Vibrator Motor Weight Settings and Instructions
Nordson
Part Number
Description Manufacturer Weight
Setting
1602109 VIBRATOR, 230/460V, 3PH/60Hz Oli−Wamgroup/MVE 60/3 66%
1602896 VIBRATOR, 330/575V, 3PH/60Hz Oli−Wamgroup/MVE 60/3 66%
1602893 VIBRATOR, 220/380V, 3PH/60Hz Oli−Wolong/MVE 60/3 66%
1602895 VIBRATOR, 200/400V, 3PH/50Hz, ATEX Oli−Wamgroup/MVE 60/3 75%
1602894 VIBRATOR, 220/380V, 3PH/50Hz Oli−Wolong/MVE 60/3 75%
1602892 VIBRATOR, 240/415V, 3PH/50Hz Oli−Wolong/MVE 60/3 75%
60Hz Motor Weight Adjustment
See Figure 8-13 for steps 1 - 4 when replacing or retrofitting a 60Hz
vibratory table motor for the Encore Powder Feed Center.
FC 66% = 2 blades turned
60Hz = 156.5 lb. FC X 66% = 103.29 lb. FC
1. Remove the caps from both ends of the motor.
2. Place wrenches on the nuts located on both ends of the motor shaft.
3. Unscrew one nut and remove the weight blades from that end of the
shaft. The opposite nut will remain tight.
NOTE: 60Hz motors come with one weight blade already rotated at each
end.
4. Place an adjustable wrench on the shaft flat. Make sure that the wrench
does not grip the threaded area of the shaft. Use another wrench to
unscrew the remaining nut. Remove the weight blades from the end of
the shaft.
To Next Page
