Description
2-14
Part 1602966−05
E 2015 Nordson Corporation
Optional Powder Hoppers
The feed center can accommodate rectangular 75-lb (34 kg) and square
50-lb (22.7 kg) fluidizing hoppers and different sizes of powder boxes.
The fluidizing hoppers are equipped with replaceable fluidizing plates and
10-mm tube fittings in the plenum. An optional cart is available for the 75-lb
hopper.
Refer to the Options section of this manual for the square and rectangular
hopper part numbers and repair parts.
18 in.
(457 mm)
36 in.
(914 mm)
16 in.
(411 mm)
18 in.
(457 mm)
18 in.
(457 mm)
17.5 in.
(444 mm)
75 lb
(34 kg)
50 lb
(22.7 kg)
Figure 2-11 Optional Fluidizing Feed Hoppers
