Options
10-6
Part 160296605
E 2015 Nordson Corporation
Operation
To turn on the Vibrasonic system, turn the red switch on the controller
clockwise 90 degrees. The POWER and VIBRASONICS indicators on the
controller will light. The five LEDs on the controller door are used for
troubleshooting. During operation, LED 1 will light to indicate normal
operation.
Troubleshooting
These procedures cover only the most common problems that you may
encounter. If you cannot solve the problem with the information given here,
contact your local Nordson representative for help.
Fault Conditions
Refer to Table 10-1 for a description of operating conditions indicated by the
LEDs and indicators.
Refer to the Troubleshooting Procedures on the following pages to identify
and correct error conditions indicated in Table 10-1.
Table 10-1 LED Functions
Condition POWER
Indicator
VIBRASONICS
Indicator
LED 1 LED 2 LED 3 LED 4 LED 5
Normal On On On Off Off Off Off
Under Voltage On On or Off Off On Off Off Off
Over Voltage On On Off Off On Off Off
Open Circuit On Flashing Off On Off On Off
Short Circuit On On Off On Off Off On
