Options
10-2
Part 1602966−05
E 2015 Nordson Corporation
75-lb Feed Hopper
See Figure 10-1.
Item Part Description Quantity Note
− 7404027 Hopper, fluidizing, powder feed center, 75 lbs. 1
1 - - - - - -
S Lid, hopper, PFC
1
2 - - - - - -
S Body, hopper, PFC
1
3 —
S Plenum, hopper
1
4 —
S Connector, 10 mm tubing x 1/2 in. NPT
1
− 1086406
S Kit, service, fluidizing hopper, PFC
5 - - - - - -
SS Fluid plate, hopper, PFC
1
6 7404175
SS Gasket, hopper, PFC
1
7 - - - - - -
SS Nut, hex, M6, nylon
40
8 - - - - - -
SS Washer, flat, M6, nylon
80
9 - - - - - -
SS Screw, hex, M6 x 40, Nylon
40
NS 1043414 Cart, fluidizing hopper 1 A
NS 1051364 Kit, handle, cart, fluidizing hopper 1 B
NOTE A: The optional cart allows the fluidizing hopper to be transported easily.
B: Order this kit to install a handle on the hopper cart.
NS: Not Shown
1
2
3
4
7
8
8
9
5
6
Figure 10-1 75-lb Feed Hopper Parts
