Description
2-1
Part 1602966−05
E 2015 Nordson Corporation
Section 2
Description
Introduction
The Encoret powder feed center conditions and supplies powder for up to
27 Venturi pumps. It contains a sieve, hopper table, lance and lift assembly,
Venturi-type in-line powder pumps, level sensors, purge manifold, and
electrical and pneumatic controls.
The feed center provides quick color changes and automatic purge
cleaning. Powder is drawn from a box or fluidized hopper powder source by
the lance-mounted, in-line powder pumps. The powder is then delivered
through feed hoses to the spray guns. The feed center can be equipped
with up to 27 Venturi pumps, and is furnished with a vibratory table to aid in
the fluidization of powder in boxes.
The feed center controls are designed to accommodate one to two HDLV
reclaim pumps to transport over-sprayed powder from the powder recovery
system to the feed center, and an optional HDLV
r
virgin pump to transport
virgin powder to the system as needed.
Figure 2-1 Encore Feed Center (Typical)
