Pneumatic Module Parts
See Figure 9-13. Refer to the 11 x 17 foldouts at the end of this manual for
the pneumatic diagram.
Item Part Description Quantity Note
1 1099413 Regulator, 0.3−7 bar, .25 3
2 1605532 Connector, male, elbow, 6MM T X R1/4 6
3 1604516 Valve, 9-station, Encore PFC 1
4 1099424 Valve, air, global PFC main interlock 1
5 1606921 Cable, valve, purge, 5 m 1
6 −−−−−− Elbow, 1 in. BSPT x 3/4 JIC 1
7 1102676 Gauge, air, 0−150 psi, rear 1/4 G thread 4
8 1100285 Regulator, air, 1 in., 0.5−12 bar 1
9 −−−−−− Manifold, Encore PFC, pneumatic 1
10 148256 Plug, 10 mm, tubing 2
11 −−−−−− Elbow, 3 port, 10 mm tube x 3/8 R 2
12 −−−−−− Vent, breather, 3/8 BSPT, sintered 3
13 1101992 Nipple, close, 1 in., (4788K416) 2
14 241040 Muffler, air 1/8 NPT 1
15 901074 Valve, airpilot, 2-way 1
16 −−−−−− Elbow, 6mm tube x 1/8 RPT 1
