Description
2-16
Part 1602966−05
E 2015 Nordson Corporation
Electrical Requirements
200V, 3 phase, 50 Hz, 6.6 amps
200V, 3 phase, 60 Hz, 6.6 amps
230V, 3 phase, 60 Hz, 6.1 amps
380V, 3 phase, 50 Hz, 3.6 amps
380V, 3 phase, 60 Hz, 3.6 amps
415V, 3 phase, 50 Hz, 3.5 amps
460V, 3 phase, 60 Hz, 3.5 amps
575V, 3 phase, 60 Hz, 2.5 amps
Air Requirements
Exhaust Air Flow
Mode Air Flow Range
Color change mode 3058 − 3228 m
3
/hr (1800 − 1900 CFM)
Paint mode 2039 − 2209 m
3
/hr (1200 − 1300 CFM)
Exhaust Air Velocity
CFM Duct Size Air Flow Velocity
1200 10 in. 2201 ft/minute
1300 10 in. 2385 ft/minute
1800 10 in. 3202 ft/minute
1900 10 in. 3485 ft/minute
Compressed Air Supply
Air input: 1 in. BSPT with NPT adapter
Air consumption at 6.9 bar (100 psi):
76 m
3
/hr (45 SCFM) − Normal operation
[ 611 m
3
/hr (360 SCFM) − Maximum
(instantaneous flow rate during purge sequence)
]
The air must be clean and dry. Use a dedicated, refrigerated or
regenerative-desiccant air dryer that can produce a 3 _C (38 _F) or lower
dewpoint at 6.9 bar (100 psi), and filter/separators with automatic drains.
