Options
10-4
Part 1602966−05
E 2015 Nordson Corporation
Vibrasonic Sieve Screen
The Vibrasonic system increases sieve screen life and powder throughput,
by applying an ultrasonic frequency to the screen. The ultrasonic frequency
breaks down the surface tension in the screen, preventing blinding.
System Components
See Figure 10-3.
5
7
9
6
4
8
2
1
3
11
12
10
Figure 10-3 Vibrasonic System Components
1. Vibrasonic controller
2. Control cable
3. Bulkhead connector
4. Transducer cable
5. Sieve deck
6. Vibrasonic transducer
7. Sieve screen
8. Cap screw
9. Sieve pan
10. Plug
11. U-gasket
12. Ground clip
To Next Page
