Options
10-5
Part 1602966−05
E 2015 Nordson Corporation
Installation
WARNING: Allow only qualified personnel to perform the following tasks.
Follow the safety instructions in this document and all other related
documentation.
WARNING: Turn off and lock out system electrical power before performing
the following tasks. Failure to observe this warning may result in personal
injury or equipment damage.
NOTE: Inspect all Vibrasonic system components for cleanliness and
damage. Contact your Nordson representative if any components are
damaged.
Vibrasonic Transducer and Sieve Screen Installation
1. See Figure 10-3. Clean the sieve screen’s (7) center hub and the bottom
of the transducer (6) with acetone.
NOTE: The transducer must be secured to the flat side of the sieve
screen hub.
2. Place the transducer on the center hub of the sieve screen. Hand
tighten the cap screw (8) through the bottom of the sieve screen.
3. Hold the base of the transducer with the supplied pin wrench and turn
the cap screw with the supplied torque wrench until you hear a click.
4. Install the U-gasket (11) and ground clip (12) on the screen.
5. Set the sieve screen into the vibratory sieve (9). Plug the transducer
cable (4) into the transducer, route the cable through the sieve deck (5),
then clamp the sieve deck onto the sieve pan.
6. Slide the transducer cable through the slit in the plug (10), then install
the plug into the sieve deck.
Controller and Cable Installation
1. See Figure 10-3. Make sure that the voltage selector on the controller
(1) is set to your system’s electrical supply specification.
2. Mount the controller above the powder feed center electrical panel as
shown in Figure 2-8.
3. Connect the control cable (2) to the controller. Route the other end to
the feed center roof.
4. Mount the bulkhead connector (3) in the feed center roof, then route the
transducer cable (4) to the bulkhead connector and plug it in.
