Installation
3-1
Part 1602966−05
E 2015 Nordson Corporation
Section 3
Installation
WARNING: Allow only qualified personnel to perform the following tasks.
Follow the safety instructions in this document and all other related
documentation.
NOTE: The feed center is typically shipped by truck or in a container. All
internal air and electrical connections are made at the factory. If it is
included as part of a ColorMax Engineered System with an integral utility
deck, all air and electrical connections to the components on the deck are
also complete. Refer to your system drawings for final connections.
Unpacking
Upon receipt, unpack the feed center carefully to avoid damage. Report
any damage immediately to the shipper and to your Nordson representative.
Save packing materials for possible later use, or dispose of properly
according to local regulations.
Preparing for Installation
Position the feed center on a level floor, or the booth utility deck, according
to the system layout drawing supplied by Nordson application engineering.
To ensure easy maintenance, provide a clear operating and access zone of
at least 1m (3 ft) wherever possible.
Extraction Duct Connection
Connect ductwork from the afterfilter/fan section to the 10 in. diameter
vertical duct at the back of the feed center.
