Description
2-17
Part 1602966−05
E 2015 Nordson Corporation
Air Pressures
Function Recommended Pressure
Lift Cylinder Up 1 Lance: 4.1 bar (60 psi)
2 Lances: 4.8 bar (70 psi)
3 Lances: 5.5 bar (80 psi)
Lift Cylinder Down 3.4 bar (50 psi)
Lift Cylinder Flow Control Valves 6 seconds full travel both directions
Purge Air 6.2 bar (90 psi)
Lance Purge Clamp Cylinder 3.4−4.1 bar (50−60 psi)
Clamp Cylinder Flow Control
Valves
3 seconds full travel both directions
Feed Hopper Fluidizing 0.3−0.7 bar (5−10 psi) (see Note)
Lance Fluidizing 0.3−0.7 bar (5−10 psi) (see Note)
NOTE: Adjust fluidizing air as needed. Powder should be gently boiling,
without geysering.
Sieves
Available Sieve Screens
381 mm (15 inch) Sieve:
864 Micron, 20 mesh without ultrasonics
381 Micron, 40 mesh without ultrasonics
234 Micron, 60 mesh, without ultrasonics
178 Micron, 80 mesh with ultrasonics
140 Micron, 100 mesh with ultrasonics
