Lift Assembly Parts
See Figure 9-2.
Item Part Description Quantity Note
− −−−−−− Lift Module 1
1 1602289
S Guide, V linear, feed center
1
2 1602290
S Plate, 3, lift carriage, with wheels
1
3 −−−−−−
S Trunnion support block
1
4 −−−−−−
S Plate, lift stop
1
5 1602292
S Bearing, IGUS
2
6 345439
S Screw, socket, M16 x 2.0 x 50, zinc
1
7 984697
S Nut, hex, jam, M16 x 2.0, steel, zinc
1
8 1602342
S Screw, socket, M8 x 1.25 x 75, zinc
4
9 982160
S Screw, socket, M8 x 1.25 x 25, zinc
4
10 1602802
S Screw, socket, M10 x 1.50 x 20, steel, zinc
6
11 982926
S Screw, socket, M8 x 12, steel, zinc
2
− −−−−−− Lift Cylinder Module 1
12 1602294
S Cylinder, locking, 63 x 600 mm, Festo
1
13 −−−−−−
S Clevis, Festo rod, M16
1
14 1603063
S Valve, flow control, .38 Rc x 6 T, meter out
2
15 1103505
S Switch, cylinder proximity
3
16 972837
S Elbow, male, 6 mm tube x 1/8 BSPT
1
17 −−−−−−
S Trunnion flange, Festo
1
18 982160
S Screw, socket, M8 x 1.25 x 25, zinc
4
