Parts
9-27
Part 1602966−05
E 2015 Nordson Corporation
Other Service Parts
Powder Transfer Tubing and Grommets
Part Description Note
1063654 Tubing, polyethylene, 16 mm OD, natural
1066079 Grommet, lip style, 3/8 in.
1100320 Plug, dome, 35 mm, (1.38 in.), Nylon
Air Tubing and Fittings
Part Description Min. Quantity
900742 Tubing, polyurethane, 6 mm OD, blue 50
900618 Tubing, polyurethane, 8 mm OD, blue 50
900619 Tubing, polyurethane, 8 mm OD, black 50
900740 Tubing, polyurethane, 10 mm OD, blue 50
900613 Tubing, polyurethane, 12 mm OD, blue 50
183804 Plug, blanking, 6 mm tube −
972930 Plug, push in, 8 mm tube, plastic −
148256 Plug, 10 mm, tubing −
Feed Hoppers
Part Description Note
1071873 Hopper, square, 50 lb A
7404027 Hopper, rectangular, 75 lb A
NOTE A: Refer to Section 10, Options for service parts.
Fittings for Transfer Pump Air
Use these fittings to supply air from the control manifold to the HDLV
transfer pump when runs are greater than 25 ft. or when dual reclaim
transfer pumps are used. Refer to Section 3, Installation for diagrams.
Part Description Note
1106371 Valve, straight fitting, 10 mm, Festo
7404027 Fitting, Y-branch, 10mm plug-in x 10 mm tube
1070536 Fitting, straight, 10 mm tube − 8 mm tube
