Parts
9-20
Part 1602966−05
E 2015 Nordson Corporation
Hopper Platform and Vibrator Parts
See Figure 9-14.
Item Part Description Quantity Note
1 1602109 Vibrator, 230/460V, 3 phase, 60 Hz 1 A
1 1602896 Vibrator, 330/575V, 3 phase, 60 Hz 1 A
1 1602895 Vibrator, 200/400V, 3 phase, 50 Hz, ATEX 1 A
1 1602894 Vibrator, 220/380V, 3 phase, 50 Hz 1 A
1 1602893 Vibrator, 220/380V, 3 phase, 60 Hz 1 A
1 1602892 Vibrator, 240/415V, 3 phase, 50 Hz 1 A
2 −−−−−− Screw, flat head, socket, M8 x 35, black 2
3 −−−−−− Screw, hex, serrated, M8 x 35, steel, zinc 2
4 1099588 Mount, vibration, isolator 4
5 −−−−−− Screw, hex, serrated, M8 x 16, steel, zinc 8
6 −−−−−− Nut, hex, flanged, serrated, M8 8
7 −−−−−− Nut, hex, machine, M5, brass 1
8 −−−−−− Washer, lock, external, M5, steel, zinc 2
9 −−−−−− Jumper, ground, 12 in. 1
10 −−−−−− Tag, ground 1
11 −−−−−− Screw, pan head, slotted, M5 x 20, brass 1
12 −−−−−− Screw, hex, serrated, M6 x 16, steel, zinc 8
13 −−−−−− Strain relief, cable, 1/2 NPT 1
14 −−−−−− Cable, SO, 4C, 16 gauge AR
15 −−−−−− Positioner, feed center hopper 2
16 1068715 Washer, lock, dished, #10 1
NOTE A: Check the identification plate on your existing motor before ordering. Before installing, verify the correct
weight adjustment to ensure proper operation. Refer to the Repair section for instructions.
AR: As Required
