Installation
3-9
Part 1602966−05
E 2015 Nordson Corporation
VIRGIN
BULK FEED
PUMP
10 mm
6 mm
6 mm
6 mm
8765
6 mm
8 mm
6 MM
8 mm
6 mm
12 mm
10 mm
6 mm
8 mm
16 mm
16 Mmm
16 mm
9432
1
TWIN CYCLONES
CONTROL MANIFOLD
VIRGIN POWDER
SOURCE
(BOX OR DRUM)
PICKUP TUBE
VIRGIN
PUMP
PANEL
Reclaim Pump
FEED CENTER SIEVE
TRANSFER PAN FLUIDIZING
VIRGIN POWDER
RECLAIM POWDER
PURGE
RECLAIM PUMP ON (SOL 336)
RECLAIM PUMP PURGE (SOL 340)
RECLAIM PUMP PURGE
RECLAIM
SHUTTLE
VALVE
VIRGIN PUMP ON (SOL 338)
VIRGIN PUMP PURGE (SOL342)
SHUTTLE
VALVE
PURGE
VALVE
RECLAIM
PURGE
VALVE
Powder Flow
Air Flow
Process Valve
BULK FEED SYSTEM (OPTIONAL)
12 mm
TO
AIR
DROP
6 mm
VIBRATOR MOTOR
IF USED
12 mm
10 mm
10 mm
Panel
Figure 3-17 Single Reclaim Pump and Optional Virgin Powder Connections and Equipment
