EXPLORER BALANCES EN-141
TABLE 9-5. SPECIFICATIONS (Cont.)
MODEL
EX6201
EX620M
EX620N
EX10201
EX10201M
EX10201N
Capacity
6200 g
10200 g
Readability d
0.1 g
Repeatability (std. dev.)
0.1 g
Linearity
+ 0.2 g
Verification interval, e
(EX…M.. / EX…N..model only)
0.1 g
Approval Class
(EX…M.. / EX…N..model only)
I
Span Calibration Points
3000g, 4000g,
5000g, 6000g
2500g, 5000g,
7500g, 10,000g
Weighing units*
g, kg, ct, oz, ozt, dwt, Grain, lb, mom, msg, tical, tola, baht, Hong Kong Tael,
Singapore Tael, Taiwan Tael, N
Weighing units
(EX…M.. model)
g, kg, ct
Applications
Weighing, Parts Counting, Percent Weighing, Check Weighing, Dynamic
Weighing, Filling, Totalization, Formulation, Differential Weighing, Peak Hold,
Density Determination, Pipette Adjustment, Ingredient Costing, Statistical Quality
Control，Fill weight Variation
Stabilization time (typical)
Within 1 second
Sensitivity Temperature Drift
(PPM/
°
C)
5
3
Typical Operating Range
USP (u=0.10%,k=2)
160g-6200g
160g-10200g
Optimal Operating Range
USP (u=0.10%,k=2)
82g-6200g
82g-10200g
Display
Full-Color VGA Graphic LCD
Display size
5.7 in / 14.5 cm (diagonal)
Backlight
White LED
Controls
4-wire resistive touch screen
Communication
RS-232, USB
Balance power input
12 VDC, 0.5A
Power supply
AC Adapter Input: 100-240 VAC 0.6A 50-60 Hz
AC Adapter Output: 12 VDC 1.5A
Platform size
190 x 200 mm
7.5 x 8.0 in
Terminal Housing dimensions
(W x D x H)
195 x 155 x 68 mm
7.7 x 6.1 x 2.7 inch
Base Housing dimensions
(W x D x H)
230 x 260 x 98 mm
9.1 x 10.2 x 3.9 inch
Assembled dimensions
(W x D x H)
230 x 393 x 98 mm
9.1 x 15.5 x 3.9 inch
Net weight
5.0 kg / 11.0 lb
Shipping weight
7.5 kg /16.5 lb
Shipping dimensions
550 x 385 x 291 mm
21.7 x 15.2 x 11.5 inch
Note 1: M = EC Type approved
N = NTEP certified and Measurement Canada approved
Note 2: Default Calibration weights shown in Bold
Note 3: * Availability is dependent on region.
