EN-142 EXPLORER BALANCES
TABLE 9-6. SPECIFICATIONS (Cont.)
MODEL
EX12001
EX12001M
EX12001N
EX24001
EX24001M
EX24001N
EX35001
EX35001M
EX35001N
Max
12000 g
24000 g
35000 g
Readability d
0. 1 g （EX…N..model：0. 1g or 1g）
Repeatability (std. dev.)
0.1 g
Linearity
+0.2 g
Verification interval, e
(EX…M.. / EX…N..model only)
1 g
Approval Class
(EX…M.. / EX…N..model only)
II
Span Calibration Points
3000g, 5000g, 10000g,
12000g
10000g, 15000g,
20000g, 24000g
10000g, 20000g, 30000g,
35000g
Weighing units*
g, kg, ct, oz, ozt, dwt, Grain, lb, mom, msg, tical, tola, baht, Hong Kong Tael,
Singapore Tael, Taiwan Tael, N
Weighing units
(EX…M.. model)
g, kg, ct
Applications
Weighing, Parts Counting, Percent Weighing, Check Weighing, Dynamic
Weighing, Filling, Totalization, Formulation, Differential Weighing, Peak Hold,
Density Determination, Ingredient Costing, Statistical Quality Control, Fill weight
Variation
Stabilization time (typical)
Within 1 second
Sensitivity Temperature Drift
(PPM/
°
C)
5
Typical Operating Range
USP (u=0.10%,k=2)
160g-12000g
160g-24000g
160g-35001g
Optimal Operating Range
USP (u=0.10%,k=2)
82g-12000g
82g-24000g
82g-35000g
Display
Full-Color VGA Graphic LCD
Display size
5.7 in / 14.5 cm (diagonal)
Backlight
White LED
Controls
2-wire resistive touch screen
Communication
RS-232, USB
Balance power input
12 VDC, 0.5A
Power supply
AC Adapter Input: 100-240 V~ 0.5A 50/60 Hz
AC Adapter Output: 24 VDC 0.625A
Platform size
377 x 311 mm
14.8 x 12.2 in
Terminal Housing dimensions
(W x D x H)
195 x 155 x 68 mm
7.7 x 6.1 x 2.7 inch
Base Housing dimensions
(W x D x H)
377 x 311 x 120 mm
14.8 x 12.2 x 4.7 inch
Assembled dimensions
(W x D x H)
442 x 311 x 120 mm
17.4 x 12.2 x 4.7 inch
Net weight
10 kg / 22 lb
Shipping weight
12 kg / 26.5 lb
Shipping dimension
665 x 525 x 330 mm
26.2 x 20.7 x 13.0 inch
Note 1: M = EC Type approved
N = NTEP certified and Measurement Canada approved
Note 2: Default Calibration weights shown in Bold
Note 3: * Availability is dependent on region.
