2-18 Service Manual
122.13 Service
Fuser Error
Fuser open thermistor check failed for
second thermistor.
Go to “Fuser service check” on
page 2-39.
122.14 Service
Fuser Error
Fuser shorted thermistor check failed
for hot roll thermistor.
Go to “Fuser service check” on
page 2-39.
122.15 Service
Fuser Error
Fuser started thermistor check failed
for second thermistor
Go to “Fuser service check” on
page 2-39.
122.16 Service
Fuser Error
EWC Error—Estimated power is at or
above maximum power.
Go to “Fuser service check” on
page 2-39.
122.17 Service
Fuser Error
Total failure to close fuser nip. Go to “Fuser service check” on
page 2-39.
141.xx Service
Staging Motor
Staging motor error. Go to “90x.xx error” on page 2-31
141.01 Service
Staging Motor
Staging motor has exceeded the ramp
up table.
Go to “90x.xx error” on page 2-31
141.02 Service
Staging Motor
Staging motor has exceeded number
of encoders at min PWM.
Go to “90x.xx error” on page 2-31
141.03 Service
Staging Motor
Staging motor has exceeded number
of encoders at max PWM.
Go to “90x.xx error” on page 2-31
141.04 Service
Staging Motor
Motor encoder count did not change
between interrupts.
Go to “90x.xx error” on page 2-31
141.05 Service
Staging Motor
Staging motor has encountered a stall
timeout.
Go to “90x.xx error” on page 2-31
150.xx Service
Black/ITU cartridge
Motor
Black/ITU Cartridge Motor Go to “Main drive gear assembly (EP
drive) service check” on page 2-41.
150.01 Service
Black/ITU cartridge
Motor
Failed to achieve lock for motor within
allotted time.
Go to “Main drive gear assembly (EP
drive) service check” on page 2-41.
150.02 Service
Black/ITU cartridge
Motor
Timeout waiting for SAP BLDC motor
to reach valid FG speed.
Go to
“Main drive gear assembly (EP
drive) service check” on page 2-41.
150.03 Service
Black/ITU cartridge
Motor
Timeout waiting for
MP_NUM_INITIAL_SAP_HALLS.
Go to “Main drive gear assembly (EP
drive) service check” on page 2-41.
150.04 Service
Black/ITU cartridge
Motor
Timeout waiting for SAP BLDC motor
FG.
Go to “Main drive gear assembly (EP
drive) service check” on page 2-41.
150.05 Service
Black/ITU cartridge
Motor
Lost lock for motor. Go to “Main drive gear assembly (EP
drive) service check” on page 2-41.
150.06 Service
Black/ITU cartridge
Motor
Excessive SAP BLDC PWM. Go to “Main drive gear assembly (EP
drive) service check” on page 2-41.
150.07 Service
Black/ITU cartridge
Motor
Motor stalled in time-based
commutation.
Go to “Main drive gear assembly (EP
drive) service check” on page 2-41.
Service error messages (1XX, 8XX and 9xx) (continued)
Error code Description Action
Y112730-2
