5-18 Service Manual
XZAC4219-05
XXX
Paper photosensor
not adjusted correctly
See “Adjusting Paper Photosensor” on
page 6 - 8
XX
Print bar not adjusted
correctly
See “Adjusting the roller gears” on page 6
- 9
XX
Wrong configuration
parameters
Reprogram the parameters of the printer.
See “Modifying configuration parameters”
on page 4 - 2
X
Document driving
belt not correctly
adjusted
See “Adjusting the document drive belt”
on page 6 - 3
X Band not adjusted
Adjust the printing band. See “Adjusting
the roller gears” on page 6 - 9
X
Roller gears not
adjusted
Adjust the gears. See “Adjusting the roller
gears” on page 6 - 9
X
Front pressure rollers
not adjusted
correctly.
Adjust the pressers of the front rollers.
“Adjusting the front pressure rollers” on
page 6 - 10
XX
Carriage belt not
calibrated
Adjust the belt for carriage movement. See
“Replacement and adjustment of belt for
carriage movement” on page 6 - 15
XX
Rear roller motor not
working
Replace the motor. See “Disassembling/
reassembling pressure roller unit” on
page 7 - 20
Fault
Possible cause Solution
The machine does
not switch on
The machine does not
connect with the system
The self-test indicates a
fault on the Motherboard
The self-text indicates an
error in the mechanics
The machine does
not switch on
The machine does not
connect with the system
