XZAC4219-05 Sercice Manual
3-1
Chapter 3 - OPERATING THE PRINTER
This chapter examines all the commands for operating the printer, operations for inserting the forms or documents
to be printed, and some maintenance procedures that can be carried out without the use of instruments or tools.
OPERATING CONTROLS
The machine has the following operating controls:
1 On/off switch.
2 Console with three keys and five LED.
3 Lever for lifting the upper part of the mechanism.
Figure 3 - 1 Operating controls
ON/OFF switch
The on/off switch of the machine is of the two-position type. The switch is operated by a mechanism that runs cross
the machine in a lengthwise direction.
